| Parameters |
Technical Details/Specifications |
| |
|
 |
| Thickness (mm) |
0.10 t0 4.00 |
| Width (mm) |
10 to 1700 (Max) |
| Cut- to -Length (mm) |
Up to 4500mm with tolerance of +2/-0 mm(Further close tolerance
on - request) |
| Coil Weight (MT) |
Up to 30 MT (7 to 18 kg/mm width) |
| Surface Finish |
Super Bright, Bright, Dull & Matte. (RaValuewith controlled Rmax on request). |
| Grades |
Specifications - As per JIS/BIS/ ASTM/EN Standards |
Low Carbon CRCA Grades
Super EDD/EDD/DD/D (SPCX, SPCEN, SPCD, SPCC) non-aging, IF-High
Strength steel (IF-HSS), High Strength Low Alloy Steel (HSLA), viz., ST -42,
ST-45, ST-52, SAPH-400/41O, Steel for Porcelein Enammeling, Corrosion
Resistant Steel, viz., Tin Mill Black Plate (TMBP) |
Medium & High Carbon CRCA Grades
C- 30, C-40,MC -ll, EN - 8, C-55, MC-12,
EN- 9 C-62, C-60, C-80, HC-14, EN-42J |
| |
ELECTRICAL Grades Elec -I, Elec-n, Elec-nI, SemiProcessed Elect. Steel |
| |
OTHER CRCA Grades
Case Hardening Steel- 15Cr3, SAE 1010, SAE 1012
Through Hardening Grades- SAE 1040, SAE 1045, 1055, 1065, 1080, 1541 |
| |
| H.R PICKLED/ SKIN PASSED & OILED |
| Thickness |
Up to 3.00 mm 3.00 mm - 4.00 mm Above 4.00 mm |
| Max. Width for Cut Size |
1500 mm 1250 mm 600 mm |
| Width for Coil |
50 mm - 1700 mm 50 mm - 1700 mm 50 mm - 1700 mm |
